RCF NX 932-A

RCF NX 932-A Активна двулентова тонколона 12"

• Up to 132 dB Sound Pressure Level
• 2100W Class-D Bi-Amplification
• 45-20000 Hz linear frequency response
• 3" Titanium/Neodymium Compression Driver
• 12" Woofer
• FiRPHASE zero degrees phase technology
• Bass Motion Control woofer excursion management
• Six M10 and four Quick Lock rigging points

Frequency Response: 45 Hz ÷ 20000 Hz

Max SPL @ 1m: 132 dB

Horizontal coverage angle: 100°

Vertical coverage angle: 70°

Transducers

Compression Driver: 1 x 1.4'' neo, 3.0'' v.c

Woofer: 12'', 2.5'' v.c

Input/Output Section

Input signal: bal/unbal

Input connectors: Combo XLR/Jack

Output connectors: XLR

Input sensitivity: -2 dBu/+4 dBu

Processor Section

Crossover Frequencies: 700Hz

Protections: Thermal, RMS

Limiter: Soft Limiter

Controls: Linear, Boost, Stage, Volume

Power Section

Total Power: 2100 W Peak

High frequencies: 700 W Peak

Low frequencies: 1400 W Peak

Cooling: Convection

Connections: Powercon TRUE1 TOP IN/OUT

Standard Compliance

Safety agency: CE compliant

Physical Specifications

Cabinet/Case Material: Plywood

Hardware:

2 x M10 Top, 1 x M10 each side, 1 x M10 bottom, 1 x M10 rear

2 each side quick lock pin seat

Handles: 1 x Side

Pole mount/Cap: Yes

Grille: Steel

Colour: Black

Size

Height: 620 mm / 24.41 inches

Width: 362 mm / 14.25 inches

Depth: 405 mm / 15.94 inches

Weight: 22.9 kg / 50.49 lbs

Shipping Information

Package Height: 666 mm / 26.22 inches

Package Width: 461 mm / 18.15 inches

Package Depth: 416 mm / 16.38 inches

Package Weight: 26 kg / 57.32 lbs
