Presonus Studiolive AR16C

Presonus Studiolive AR16C
Presonus Studiolive AR16C
Presonus Studiolive AR16C
Presonus Studiolive AR16C
Presonus Studiolive AR16C
Presonus Studiolive AR16C
Presonus Studiolive AR16C
Presonus Studiolive AR16C
  • 18x4 24-bit/96 kHz, USB 2.0 (over USB-C™ connection) audio recording interface; record every channel plus the main mix
  • 2x2 SD recorder (record main mix); supports SD and SDHC formats up to 32 GB
  • 18-channel analog mixer with:
  • 12 balanced microphone inputs with XMAX mic preamps plus two instrument inputs, 16 balanced line level inputs, and 2 insert points
  • Stereo Super Channel (Ch. 17/18) with Bluetooth®0 wireless, RCA inputs, 1/8-inch stereo input, and switchable SD/USB stereo playback
  • Stereo effects processor with 16 presets, dedicated send and return, and bypass footswitch jack
  • Complete recording solution: Includes Capture™ live-recording software and Studio One Pro License for Mac® and Windows


General
Product NameStudioLive® AR16c Analog Mixer, Blue, 230-240V EU
Model #2779206102
SeriesStudioLive®
ColorBlue
Country Of OriginVN
Electronics
Voltage220-240V EU
Phantom Power+48 VDC
Performance
Digital Audio Bit Depth24
Digital Audio Dynamic Range105 dB (A-Weighted, 48 kHz)
Inputs
Instrument Input1/4” TS Female, Unbalanced, Hi-Z
Instrument Inputs Dynamic Range> 108 dB
Instrument Inputs Frequency Response20 Hz to 20 kHz, +0.5/-1.5 dB
Instrument Inputs Gain Range43 dB (+12 to +55 dB)
Instrument Inputs Max Level+9 dBu
Line Input Type1/4" TRS, Balanced
Line Inputs Frequency Response20 Hz to 20 kHz, +0.5/-1.5 dB
Line Inputs Gain RangeMono: 40 dB, Stereo: 0 dB / +10 dB
Line Inputs Impedance10 kΩ
Line Inputs Max Level+26 dBu
Line Inputs S/N Ratio85 dB
Line Inputs THD< 0.01%
Mic Input TypeXLR Female, Class A XMAX
Mic Preamp CMRR65 dB
Mic Preamp EIN< 128 dBu
Mic Preamp Frequency Response20 Hz to 20 kHz, +0.5/-1.5 dB
Mic Preamp Gain Range43 dB (+12 to +55 dB)
Mic Preamp Input Impedance1 kΩ
Mic Preamp Max Input Level+9 dBu
Mic Preamp S/N Ratio94 dB
Mic Preamp THD< 0.01%
Outputs
Headphone Dynamic Range>103 dB (A-Weighted)
Headphone Frequency Response20 Hz to 20 kHz
Headphone Max Output150 mW /Channel at 60 Ω
Headphone THD< 0.01%
Line Output Type1/4" TRS, Balanced
Line Output Max Level+18 dBu
Line Output Impedance100 Ohms
Main and Line Output Frequency Response20 Hz to 20 kHz
Main and Line Output THD< 0.01%
Hardware
USB Recording PortUSB 2.0
Measurements
Dimensions3.70 x 20.00 x 15.00 IN
Shipping Weight14.10 LB
Product Depth15.56" (397 mm)
Product Height3.5” (90 mm)
Product Width18.9" (48.01 cm)
Shipping Dimensions3.70 x 20.00 x 15.00 IN
Miscellaneous
DisclaimerWARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Commodity Code8543700600
Power CableIEC
Supported Sample Rates44.1, 48, 88.2, 96 kHz

Напишете мнение

Забележка: HTML не се потдържа!
Лош Добър
Presonus Studiolive AR16C
  • Наличност: В наличност
  • Модел: STUDIOLIVE AR16C
  • SKU: 2779206102
628.90€
99999 или повече 628.90€
